Type |
NLS0.6 |
NLS1 |
NLS1.5 |
NLS2 |
NLS3 |
|
Screen Area (m2) |
0.6 |
1 |
1.5 |
2 |
3 |
|
Concentration of Input Pulp(%) |
0.4-0.8 |
||||
|
Capacity (Screen Hole) (t/d) |
30-60 |
70-130 |
110-160 |
140-260 |
250-400 |
|
Capacity (Screen Slot) (t/d) |
25-45 |
55-80 |
80-120 |
100-160 |
150-300 |
|
Pressure of Inflow Pulp(mpa) |
0.1-0.4 |
||||
|
Motor Power (kw) |
7.5-15 |
22 |
30 |
37 |
45 |
|
Type |
NLS4 |
NLS5 |
NLS6 |
NLS7 |
|
Screen Area (m2) |
4 |
5 |
6 |
7 |
|
Concentration of Input Pulp(%) |
0.4-0.8 |
|||
|
Capacity (Screen Hole) (t/d) |
260-520 |
350-600 |
420-700 |
500-900 |
|
Capacity (Screen Slot) (t/d) |
180-320 |
220-400 |
260-480 |
350-600 |
|
Pressure of Inflow Pulp(mpa) |
0.1-.0.4 |
|||
|
Motor Power (kw) |
55 |
75 |
90 |
110 |
|
Type |
NLS8 |
NLS9 |
NLS10 |
NLS11 |
|
Screen Area (m2) |
8.5 |
9.6 |
10.5 |
12 |
|
Concentration of Input Pulp(%) |
0.4-0.8 |
|||
|
Capacity (Screen Hole) (t/d) |
600-1120 |
700-1200 |
770-1300 |
840-1400 |
|
Capacity (Screen Slot) (t/d) |
400-720 |
440-800 |
480-880 |
520-960 |
|
Pressure of Inflow Pulp(mpa) |
0.1-.0.4 |
|||
|
Motor Power (kw) |
110 |
132 |
160 |
160 |
