PX Series Eccentric Pulper-Zhengzhou Leizhan Technology Paper Machinery Co., Ltd.

Application and features

1.lt is used to pulp all kinds of waste paper, virgin pulp board and paper machine broken paper.
2.Rotor and sieve plate with eccentrically design, double cone structure.
3.Lower energy consumption, 20% energy saving than traditional pulper.
4.The twisted rope of the Ragger has a wider movement area, the twisted rope is far away from the rotor,the rotor load is smaller, and the risk of twisted rope breakage is reduced.

Main Specification

PX-V Eccentric Pulper
Model	PX15-V	PX20-V	PX25-V	PX30-V	PX35-V	PX40-V	PX50-V	PX65-V	PX85-V	PX107-V
Nominal volume: m3	15	20	25	30	35	40	50	65	85	107
Treatment consistency:	4-8
Capacity: t/d	60-90	80-120	120-170	140-190	10-230	220-290	300-400	400-550	600=700	800-1000
Motor power: kw	110	132	160	220	250	280	355	500	630	800
